Introduction

Our catalytic methanation systems convert hydrogen and carbon dioxide into synthetic methane and water. A wide range of sources of CO_₂ gas (biogas, syngas, or pure CO_₂) can be used.

We’re an experienced system integrator with the know-how to provide catalytic methanation solutions in modular configurations and fully integrate them into your infrastructure. Our end-to-end methanation solution can also include upstream or downstream process equipment.

Our single-stage reactors work on the basis of the gravitational flow principle, rely on a minimum of moving parts, and are economical in terms of power consumption. The oil-free system also enables the temperature to be reliably maintained at around 280°C and allows the stable production of high volumes of methane.

Our catalytic methanation system produces a dry, methane-rich product gas at moderate pressures, ideal for direct use, feeding into the gas grid, or liquefaction. The system can also be designed to provide fully demineralised water and high-temperature process heat, which allows good overall efficiency.

Advantages

• Wide range of H₂/CO₂ ratios accepted

• Long-term availability of the Ni catalyst

• Simple reactor control by natural draft water/steam circulation cooling

• Low power consumption

• Low operation and maintenance cost

• Europe-wide service network in

• cooperation with local partners
